Operating mechanism for ZW32-12 Outdoor Vacuum Circuit Breaker /Intelligent Type

Operating mechanism for ZW32-12 Outdoor Vacuum Circuit Breaker /Intelligent Type Introduction

Welcome to the product page for the Operating Mechanism for ZW32-12 Outdoor Vacuum Circuit Breaker / Intelligent Type, an essential component designed to enhance the performance and reliability of electrical systems. Manufactured by Shaanxi Huadian Electric Co., Ltd., a leader in high-tech circuit breaker solutions, this operating mechanism reflects our commitment to quality, safety, and innovation.

At Shaanxi Huadian, we leverage nearly 10,000 square meters of cutting-edge production facilities and a fully automated assembly line to produce high-quality circuit breakers that meet international standards. Our ISO9001:2000 certification guarantees that our products undergo rigorous quality control, ensuring you receive only the best.

Product Features and Advantages

The Operating mechanism for ZW32-12 Outdoor Vacuum Circuit Breaker /Intelligent Type boasts several advanced features, making it a top choice for medium and large companies:

• High Reliability: Engineered for exceptional performance in demanding environments, our operating mechanism ensures reliable circuit operation and minimizes downtime.
• Intelligent Control: Integrated with smart technology, it allows for real-time monitoring and control, enhancing operational efficiency.
• User-Friendly Design: The intuitive interface simplifies operation and maintenance, making it accessible for all users.
• Durable Construction: Designed to withstand harsh outdoor conditions, this mechanism offers extended service life and reduced maintenance costs.

Product Structure

The operating mechanism consists of several key components:

• Mechanical Assembly: Durable parts designed to endure high operational stress.
• Electronic Control Unit: Provides intelligent functionality and monitoring.
• Protection Housing: Ensures safety and protection from environmental factors.

Together, these components create a robust and reliable mechanism that meets the rigorous demands of modern electrical systems.

Main Technical Parameters

Here are the essential technical specifications for the Operating mechanism for ZW32-12 Outdoor Vacuum Circuit Breaker /Intelligent Type:

• Rated Voltage: 12 kV
• Rated Current: 630 A
• Breaking Capacity: 20 kA
• Operating Mechanism Type: Spring-operated
• Weight: Approximately 100 kg

These parameters are crucial for ensuring compatibility with existing systems and maximizing performance.

Product Use Conditions

This operating mechanism is designed to perform optimally under the following conditions:

• Temperature Range: -40°C to +40°C
• Altitude: Up to 2000 meters above sea level
• Humidity: 95% relative humidity at 20°C

These specifications make it suitable for various environments, including power plants, urban construction, and rural network transformation projects.

Application Scope and Field

The Operating Mechanism for ZW32-12 is widely applicable across multiple industries, including:

• Power Generation: Essential for maintaining reliability in power plants.
• Metallurgy: Used in the electrical systems of metallurgical operations.
• Petrochemical: Crucial for safety and efficiency in petrochemical processing.
• Transportation: Integrated into railway systems for enhanced electrical safety.

These diverse applications highlight the versatility and reliability of our product.

Power plants and substations

Industrial power distribution systems

Railways and urban infrastructure

Mining and petrochemical industries

OEM Service

At Shaanxi Huadian, we understand the unique needs of our customers. We offer tailored OEM services to meet specific project requirements, ensuring that our products align perfectly with your operational standards. Our dedicated R&D team is here to support you with any customizations or innovations you may need.

FAQ

Q: What makes the ZW32-12 operating mechanism different from other circuit breakers?
A: The ZW32-12 features advanced intelligent control technology, providing enhanced monitoring and operational efficiency, which is not typically found in standard circuit breakers.

Q: Is technical support available after purchase?
A: Yes, we provide comprehensive technical support to assist with product application, installation, and maintenance.

Q: How can I ensure timely delivery of my order?
A: We maintain a stable supply chain and closely monitor production schedules to meet your delivery needs.
