XGN7-12 Box type fixed metal enclosed switchgear Introduction

The XGN7-12 Box type fixed metal enclosed switchgear is a high-performance solution designed for power distribution systems that require reliable, safe, and efficient operation.

Manufactured by Shaanxi Huadian Electric Co., Ltd., a leader in electrical switchgear technology, this product combines modern design with advanced functionality to meet the needs of various industrial sectors such as power plants, metallurgy, petrochemical, mining, and urban construction. This switchgear ensures optimal protection and control for medium voltage electrical systems, supporting industries in maintaining a stable and secure power supply.

product-1-1

Features and Advantages

Compact Design: The XGN7-12 switchgear is designed to save space while providing maximum functionality in a small footprint.
Safety and Reliability: Equipped with advanced insulation and protection technologies, this switchgear ensures safe operation in various industrial environments.
Durability: The product is constructed with high-quality materials, offering long-term performance and reduced maintenance costs.
Easy Installation and Maintenance: With its modular structure, the XGN7-12 is easy to install and maintain, minimizing downtime for businesses.
Eco-Friendly: Compliant with environmental standards, the XGN7-12 Box type fixed metal enclosed switchgear is designed to reduce energy consumption and carbon footprint.

Product Structure

The XGN7-12 box-type fixed metal enclosed switchgear consists of several key components that work together to ensure reliable performance:

Circuit Breaker Unit: Protects against overloads and short circuits.
Busbar System: Efficiently distributes electrical power.
Instrument Compartments: Provides space for monitoring and controlling the switchgear.
Safety Interlocks: Prevents unsafe operation by securing various sections of the switchgear during maintenance.

XGN7-12 Box type fixed metal enclosed switchgear03

XGN7-12 Box type fixed metal enclosed switchgear04

Main Technical Parameters

Rated Voltage: 12kV
Rated Current: 630A to 1250A
Short-Circuit Breaking Current: 20kA to 31.5kA
Frequency: 50Hz
Protection Level: IP4X
Ambient Temperature: -15°C to +40°C

Projects	Unit	VS1
Rated voltage	kV	3.6,7.2,12
Rated current	A	630,1250,1600,2000,3150
Rated short circuit opening current	kA	16,20,31.5,40
Rated short circuit breaking current (peak value)	kA	40,50,80,100
Rated short circuit stable moving current (peak value)	kA	40,50,80,100
Rated heat stable heating current	kA	16,20,31.5,40
Rated heat stable heating time	S	4
Protection grade		IP2X
Structure type		Single bus bar disjunction and single bus bar with branches
Operation mode		electromagnetic,spring and energy storage type
The external dimension width X deep X is high	mm	1100×1200×2650(common type)
Weight	kg	1000

Product Use Conditions

The XGN7-12 Box type fixed metal enclosed switchgear is suitable for both indoor and outdoor use under the following conditions:

Ambient Temperature: Between -15°C and +40°C
Altitude: ≤1000m
Humidity: Maximum relative humidity of 90% at +25°C
Pollution Level: Suitable for environments up to pollution level III

Application Scope and Field

The XGN7-12 is widely used in:

Power Plants: Ensures safe distribution of electrical power in power generation facilities.
Metallurgy: Supports heavy-duty operations in metal production environments.
Petrochemical Industry: Offers reliable protection and control for electrical systems in high-risk environments.
Urban Construction and Infrastructure: Plays a crucial role in ensuring a stable power supply for urban development projects.
Mining: Provides robust XGN7-12 Box type fixed metal enclosed switchgear and operational control in harsh mining conditions.
Rural Network Transformation: Ideal for upgrading rural power grids for improved efficiency and reliability.

Power plants and substations

Industrial power distribution systems

Railways and urban infrastructure

Mining and petrochemical industries

Power plants and substations

Industrial power distribution systems

Railways and urban infrastructure

Mining and petrochemical industries

OEM Service

Shaanxi Huadian Electric Co., Ltd. offers OEM services to cater to the specific needs of businesses. We work closely with clients to design and manufacture custom switchgear solutions that meet unique operational requirements, ensuring product compliance with local and international standards. Our technical team provides full support from design to implementation, helping your business get the best switchgear solutions tailored to your needs.

FAQ

What is the rated voltage of the XGN7-12 switchgear?
The rated voltage is 12kV, making it suitable for medium voltage applications.
Is the XGN7-12 switchgear easy to maintain?
Yes, its modular design allows for easy installation and maintenance, reducing downtime.
What industries can benefit from using the XGN7-12 switchgear?
This product is ideal for power plants, metallurgy, petrochemical, urban construction, mining, and rural network upgrades.
Does Shaanxi Huadian provide technical support for this product?
Yes, we offer comprehensive technical support to ensure optimal performance and seamless integration into your system.
Can I request a custom design?
Absolutely. Our OEM services of XGN7-12 Box type fixed metal enclosed switchgear are designed to provide tailored solutions based on your specific requirements.
