VEGM-12/PT Potential Transformer Handcart
2. **Rated Current**: Designed to handle up to 630A, the handcart operates effectively under normal working conditions.
3. **Tripping Capacity**: Capable of interrupting fault currents up to 31.5kA, providing dependable fault isolation.
4. **Tripping Time**: Fast response with a tripping time of less than 50ms, ensuring quick fault management.
5. **Operation Mode**: The handcart supports manual and electric operation for flexibility in control.
6. **Distance**: Maintains a minimum contact distance of 210mm after disconnection, ensuring safety and insulation.
7. **Delivery**: Available for global shipping via sea, air, or express delivery options.
8. **Packaging**: The product is securely packaged in reinforced wooden crates for safe transport.
VEGM-12/PT Potential Transformer Handcart Manfufacturer
Welcome to Shaanxi Huadian Electric Co., Ltd., a leading manufacturer in vacuum circuit breaker solutions. Our VEGM-12/PT Potential Transformer Handcart is designed to meet the highest industry standards, offering reliable and efficient service for medium and large-scale operations. This page will provide all the essential details to help you make an informed decision.
Product Introduction
The VEGM-12/PT Potential Transformer Handcart is a critical instrument utilized in high-voltage systems, specifically designed to accurately measure essential electrical parameters such as voltage. Crafted with meticulous precision engineering, this handcart guarantees reliable and precise measurements, which are vital for the optimal performance of your power system.
Product Features and Advantages
- High Precision: The VEGM-12/PT ensures accurate voltage measurement, which is critical for the stability and safety of power systems.
- Durability: Manufactured with high-quality materials and advanced production techniques, this product offers exceptional durability, reducing maintenance needs over time.
- Compact Design: Its compact structure allows for easy installation and smooth integration into various electrical systems, saving space while maintaining functionality.
- Enhanced Safety: Designed with safety in mind, the VEGM-12/PT incorporates insulation and protection mechanisms to prevent electrical faults.
- Versatility: This potential transformer handcart is adaptable for multiple applications, providing flexibility for different industrial uses.
Product Structure
The VEGM-12/PT Potential Transformer Handcart consists of several key components:
- High-Strength Frame: Made from reinforced materials to withstand high voltages.
- Potential Transformer: Accurately measures voltage levels and transmits the data to the monitoring system.
- Insulation: Advanced insulation techniques ensure safe and reliable operation.
- Wheels: Equipped with sturdy wheels for easy movement and placement.
Main Technical Parameters
| Parameter | Details |
|---|---|
| Rated Voltage | 12kV |
| Rated Frequency | 50Hz |
| Primary Voltage | 11-12kV |
| Secondary Voltage | 100V |
| Accuracy Class | 0.2 |
| Power Frequency Withstand | 42kV |
| No. | Item | Unit | Data | ||
| 1 | Rated Voltage | Kv | 12 | ||
| 2 | Rated Current | A | 630 / 1250 | ||
| 3 | Power Frequency Withstand Voltage of the Secondary Circuit | V | 2000 | ||
| 4 | Contact Distance | A | 15~17 | ||
| 5 | Rated Frequency | Hz | 50 | ||
| 6 | Rated Operation Sequence | s | o-0.3s-co-180s-co | ||
Prodection Details
Product Outline and Installation Dimensions:
(Unit:mm)
Product Use Conditions
To ensure optimal performance, the VEGM-12/PT should be used under the following conditions:
- Ambient temperature between -25°C and 40°C.
- Altitude less than 1,000 meters.
- Humidity not exceeding 95% at 25°C.
- No exposure to corrosive gases or flammable materials.
Product Application Scope and Field
The Potential Transformer Handcart is widely used across industries such as:
- Power Generation Plants: Ensuring stable and reliable voltage monitoring.
- Railway Systems: Providing accurate voltage measurement for efficient rail operations.
- Petrochemical Plants: Supporting safe and stable operations through reliable electrical monitoring.
- Urban and Rural Power Grids: Ensuring the accuracy of voltage measurements for grid stability.
- Mining and Metallurgy: Aiding in the smooth operation of heavy-duty electrical systems.
OEM Services
At Shaanxi Huadian Electric Co., Ltd., we offer flexible OEM services for the Potential Transformer Handcart. Our team is ready to customize products according to your specific needs, ensuring you get the best fit for your operations. Whether it’s size, capacity, or design, we work closely with you to deliver exactly what you require.
FAQ
- What is the lifespan of the VEGM-12/PT Potential Transformer Handcart?
- The handcart is built to last over 20 years with proper maintenance.
- Can this handcart be customized?
- Yes, we offer customization options to meet your specific operational needs.
- How long is the delivery time?
- Standard models can be delivered within 30 days, while customized units may take slightly longer.
- Is technical support provided?
- Yes, we offer full technical support, including installation guidance and after-sales service.
- What are the payment terms?
- We accept bank transfers and credit card payments. Flexible payment options are available for large orders.
Our Factory and Certificates
 |
 |
 |
|
|
|
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Contact Us
For more information about the VEGM-12/PT Potential Transformer Handcart or to request a quote, please contact us at:
- Email: austinyang@hdswitchgear.com/rexwang@hdswitchgear.com/pannie@hdswitchgear.com
- Phone: +86-0917-6735 959
- Address: Shaanxi Huadian Electric Co., Ltd., Baoji High-tech Development Zone, Shaanxi Province
