ZN63A(VS1)-24/YD Electric Handcart

ZN63A(VS1)-24/YD Electric Handcart Introduction

The ZN63A(VS1)-24/YD Electric Handcart is a high-performance vacuum circuit breaker designed for medium-voltage power systems. This product, developed by Shaanxi Huadian Electric Co., Ltd., offers reliable performance in various industries, ensuring stable power control and protection. It is engineered for long-term use, with advanced technology to guarantee safety and operational efficiency, making it ideal for medium to large-scale procurement needs.

Product Features and Advantages

• High Stability and Durability: Designed for rigorous industrial environments, the ZN63A(VS1)-24/YD Electric Handcart excels in offering long-term operational stability.
• Advanced Vacuum Interruption: This handcart uses vacuum technology for circuit interruption, ensuring safe and efficient operation with minimal wear and tear.
• Automated Operation: The electric handcart design allows for automated movements, increasing operational efficiency in busy production settings.
• Compact and Efficient Design: The compact structure ensures easy integration into existing systems, while maintaining high electrical efficiency.
• Certified Quality: The product complies with ISO9001:2000 quality system standards, ensuring customers receive the best quality available.

Product Structure

The ZN63A(VS1)-24/YD Electric Handcart consists of a vacuum circuit breaker unit mounted on a mobile handcart system. The handcart mechanism allows for easy insertion and removal from its enclosure, facilitating maintenance and reducing downtime. The primary components include:

1. Vacuum interrupter – ensuring arc extinction in high-voltage conditions.
2. Spring-operated mechanism – for quick and efficient switching operations.
3. Control panel – equipped with necessary interfaces for operation and monitoring.

Main Technical Parameters

• Rated Voltage: 24kV
• Rated Current: Up to 1250A
• Rated Short-Circuit Breaking Current: 31.5kA
• Mechanical Life: 10,000 operations
• Control Voltage: 220V AC/DC These parameters ensure that the handcart performs reliably across a range of industrial applications, delivering consistent results.

Product Use Conditions

• Ambient Temperature: -25°C to +40°C
• Altitude: Up to 2000 meters
• Humidity: Suitable for areas with relative humidity up to 95%
• Vibration Resistance: Built to withstand moderate vibrations, making it ideal for heavy industrial environments.

Product Application Scope

The ZN63A(VS1)-24/YD Electric Handcart is widely used in industries such as:

• Power plants
• Metallurgy
• Petrochemical industries
• Railways
• Mining operations
• Urban and rural grid transformation projects Its robust design and reliable functionality make it a preferred choice for medium to large-scale applications requiring frequent circuit management.

Power plants and substations

Industrial power distribution systems

Railways and urban infrastructure

Mining and petrochemical industries

OEM Services

At Shaanxi Huadian Electric Co., Ltd., we pride ourselves on providing comprehensive customized OEM services designed to meet the unique needs of our clients. Our professional R&D team, equipped with extensive expertise and experience, is ready to collaborate closely with businesses to develop tailored solutions that precisely address their specific operational requirements. Whether it involves adjusting technical specifications to enhance performance or integrating our products with specialized systems for seamless functionality, we guarantee exceptional flexibility and commitment in delivering high-quality products that align perfectly with customer expectations and enhance their operational efficiency.

FAQ

Q1: What is the lead time for delivery? A1: The typical lead time is 4-6 weeks, depending on the order size and customization needs.

Q2: Can this product be used in high-altitude regions? A2: Yes, the ZN63A(VS1)-24/YD Electric Handcart is suitable for use at altitudes up to 2000 meters.

Q3: Does the product come with a warranty? A3: Yes, we offer a 12-month warranty from the date of installation.

Q4: Can I request custom modifications to the product? A4: Absolutely! We offer OEM services to accommodate any customization requirements.

Q5: What certifications does this product hold? A5: The product is ISO9001:2000 certified, ensuring top-notch quality and reliability.
