Chassis of high voltage switchgear complete set
2. **Rated Current**: Designed to handle continuous currents of up to 3150A, this chassis guarantees efficient operation under normal working conditions.
3. **Tripping Capacity**: With a tripping capacity of 40kA, this chassis effectively cuts off the maximum fault current, enhancing system protection.
4. **Tripping Time**: The circuit breaker features a swift tripping time of less than 0.1 seconds, ensuring rapid response during fault conditions.
5. **Operation Mode**: Available in various operation modes, including manual and electric, allowing flexibility in operation based on user preference.
6. **Distance**: The minimum distance between contacts after disconnection is maintained at 10mm, ensuring safety and reliability.
7. **Delivery**: Our products are shipped worldwide through reliable carriers, with options for express and standard delivery based on customer needs.
8. **Packaging**: Each chassis is securely packaged in durable outer boxes to prevent damage during transit, ensuring safe delivery to our customers.
Chassis of High Voltage Switchgear Complete Set
The Chassis of High Voltage Switchgear Complete Set from Shaanxi Huadian Electric Co., Ltd. is a high-quality, precision-engineered product designed to meet the demanding needs of medium and large enterprises. Our chassis is an essential component for safe and efficient power distribution in various high-voltage applications, ensuring operational stability and compliance with international standards. With over two decades of experience in the vacuum circuit breaker industry, Shaanxi Huadian is your trusted partner for reliable and advanced switchgear solutions.
Key Features and Advantages
- High-Performance Durability: Crafted from premium materials, the chassis offers exceptional durability, able to withstand extreme conditions in industrial environments.
- Precise Engineering: Developed using advanced manufacturing techniques, including fully automated control assembly lines, ensuring consistent and flawless performance.
- Customization Available: We offer tailored solutions to meet the unique specifications of your power systems.
- Certification Compliance: Our products meet ISO9001:2000 certification standards, ensuring high quality and safety for our clients.
Product Structure
The chassis consists of a robust framework built to house and support the internal components of high voltage switchgear. Designed for easy integration with various switchgear setups, it ensures seamless assembly and future maintenance. The lightweight yet sturdy design helps reduce downtime during installation while providing strong protection against external impacts and internal system pressure.
Technical Specifications
- Rated Voltage: Up to 40.5kV
- Current Capacity: Up to 4000A
- Short Circuit Withstand: Up to 40kA
- Material: High-strength steel with anti-corrosive coatings
- Dimensions: Customizable based on client needs
- Weight: Varies according to configuration
Usage Conditions
The chassis is designed for optimal performance in high-voltage switchgear applications. It can be deployed in environments with:
- Ambient temperatures ranging from -25°C to +40°C
- Humidity levels below 95%
- Altitudes up to 1000 meters above sea level For higher altitudes or extreme environmental conditions, please consult with our technical team for custom solutions.
Application Scope
Our Chassis of High Voltage Switchgear Complete Set is ideal for use in:
- Power plants
- Metallurgy
- Petrochemical industries
- Railway and mining sectors
- Urban construction projects
- Rural power grid transformations
OEM Services
At Shaanxi Huadian Electric Co., Ltd., we provide OEM services to suit your specific project requirements. Our technical team works closely with your engineers to design, develop, and manufacture chassis tailored to your needs. With our ERP, PDM, and CIM systems in place, we ensure seamless production processes and timely delivery.
FAQ
Q: What kind of certifications do your products comply with?
A: All our products, including the chassis, are ISO9001:2000 certified, ensuring top-notch quality and reliability.
Q: Can I customize the chassis dimensions?
A: Yes, we offer full customization based on your specific project requirements.
Q: How long is the delivery time for custom orders?
A: Delivery times depend on the complexity of your order, but typically range from 6 to 8 weeks for custom products.
Q: Do you offer technical support for installation?
A: Yes, our team provides full technical support to ensure smooth installation and integration into your systems.
 |
 |
 |
|
|
|
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Contact Us
For inquiries, quotations, or more information on the Chassis of High Voltage Switchgear Complete Set, feel free to contact us at:
Email: austinyang@hdswitchgear.com/rexwang@hdswitchgear.com/pannie@hdswitchgear.com
Phone: +86-0917-6735 959
